Printing Technology:
Control Panel:
6 switches and 10 LEDsPrint Direction:
Bi-direction with logic seekingPrinting Method:
Impact dot matrixNumber of Pins in Head:
9 pinsControl Code:
ESC/P2, IBM PPDS
Print Characteristics:
Bitmap Fonts:
Epson Draft: 10, 12, 15 cpiScalable Fonts:
Epson Roman / Epson Sans SerifBarcode:
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET
Paper Media:
Cut Sheet (Single Sheet):
Entry: Front
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.065 - 0.14 mm | (0.0025 - 0.0055”)
Entry: Rear
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.065 - 0.14 mm | (0.0025 - 0.0055”)Cut Sheet (Multi-part Sheet):
Entry: Front
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.12 - 0.46 mm | (0.0047 - 0.018”)
Entry: Rear
Length: 100 - 420 mm | (3.9 - 16.5”)
Width: 100 - 420 mm | (3.9 - 16.5”)
Thickness: 0.12 - 0.46 mm | (0.0047 - 0.018”)Continuous Paper (Single Sheet / Multi-part):
Copies:
Original + 4 copies
Entry: Front / Rear / Bottom
Length: 101.6 - 558.8 mm | (4.0 - 22.0”)
Width: 101.6 - 406.4 mm | (4.0 - 16.0”)
Thickness: 0.065 - 0.46 mm | (0.0025 - 0.018”)Envelope (No.6):
Entry: Rear
Length: 92 mm | (3.6”)
Width: 165 mm | (6.5”)
Thickness: 0.16 - 0.52 mm | (0.0063 - 0.0205”)Envelope (No.10):
Entry: Rear
Length: 105 mm | (4.1”)
Width: 241 mm | (9.5”)
Thickness: 0.16 - 0.52 mm | (0.0063 - 0.0205”)Label (Base Sheet):
Entry: Buttom
Length: 101.6 - 558.8 mm | (4.0 - 22.0”)
Width: 101.6 - 406.4 mm | (4.0 - 16.0”)
Thickness: 0.16 - 0.19 mm | (0.0063 - 0.0075”)Card:
Entry: Front / Rear
Length: 100 - 148 mm | (3.9 - 5.8”)
Width: 100 - 148 mm | (3.9 - 5.8”)
Thickness: 0.22 mm | (0.0087”)Roll Paper:
Entry: Rear
Diameter: 127mm | (5”)
Width: 216 mm | (8.5”)
Thickness: 0.07 - 0.09 mm | (0.0028 - 0.035”)Line Spacing:
4.23mm (1/6”) or programmable in increments of 0.059mm (1/432”)
